| Lugar de origen: | Porcelana |
| Nombre de la marca: | FLYROM |
| Certificación: | CE,ROHS |
| Número de modelo: | CWDM-MD-16CH-ABS |
| Cantidad de orden mínima: | 1 pieza |
|---|---|
| Precio: | Please send inquiry to sales@flyromtech.net |
| Detalles de empaquetado: | Embalaje neutro |
| Tiempo de entrega: | 3-7 días laborables |
| Condiciones de pago: | T/T, LC/C |
| Capacidad de la fuente: | 10000 unidades/mes |
| 1270 nm: | 1290nm | 1310nm: | 1330NM |
|---|---|---|---|
| 1350nm: | 1370nm | 1390 nm: | 1410 nm |
| 1430 nm: | 1450nm | 1470nm: | 1490 nm |
| 1510 nm: | 1530nm | 1550nm: | 1570 nm |
| 1590nm: | 1610nm |
Features
Applications
Specification
| Parameter | 16 Channel | ||
| Mux | Demux | ||
| Channel Wavelength(nm) | 1310-1610 | ||
| Center wavelength Accuracy(nm) | ±0.5 | ||
| Channel Spacing (nm) | 20 | ||
| Channel Passband(@-0.5dB bandwidth (nm) | >13 | ||
| Insertion Loss(dB) | ≤3.5 | ||
| Channel Uniformity(dB) | ≤1.5 | ||
| Channel Ripple(dB) | 0.3 | ||
| Isolation(dB) | Adjacent | N/A | >30 |
| Non-adjacent | N/A | >40 | |
| Insertion Loss Temperature Sensitivity(dB/℃) | <0.005 | ||
| Wavelength Temperature Shifting(nm/℃) | <0.002 | ||
| Polarization Dependent Loss(dB) | <0.1 | ||
| Polarization Mode Dispersion(PS) | <0.1 | ||
| Directivity(dB) | >50 | ||
| Return Loss(dB) | >45 | ||
| Maximum Power Handling(mW) | 500 | ||
| Operating Temperature(℃) | -5~+75 | ||
| Storage Temperature (℃) | -40~85 | ||
| Package dimension(mm) | L140xW115xH18 | ||
| Fiber Type | 1.0meter ,3.0mm loose tube | ||
| Connector type | tx/rx LC/UPC, com/exp port SC/UPC | ||
Above specification are for device with connectors
Order Information
| Configuration | Channel No. | Channel | Pigtail Type | Fiber length | Dimensio(mm) | Connector |
| M=Mux D=Demux |
04=4 Channel 08=8 Channel 16=16 Channel
N=N Channel …… |
27=1270nm 47=1470nm 49=1490nm …… 61=1610nm SS=special… |
0=250um 1=900um 2=2.0mm |
1=1m 2=1.5m 3=others |
1= L100 x W80 xH10 2=L140xW100xH15 3=19 1U Rack |
0=None 5=others |
