| Lugar de origen: | Porcelana |
| Nombre de la marca: | FLYROM |
| Certificación: | CE,ROHS |
| Número de modelo: | CWDM-MD-2CH-LGX |
| Cantidad de orden mínima: | 1 pieza |
|---|---|
| Precio: | Please send inquiry to sales@flyromtech.net |
| Detalles de empaquetado: | Embalaje neutro |
| Tiempo de entrega: | 3-7 días laborables |
| Condiciones de pago: | T/T, LC/C |
| Capacidad de la fuente: | 10000 unidades/mes |
| 1270 nm: | 1290nm | 1310nm: | 1330NM |
|---|---|---|---|
| 1350nm: | 1370nm | 1390 nm: | 1410 nm |
| 1430 nm: | 1450nm | 1470nm: | 1490 nm |
| 1510 nm: | 1530nm | 1550nm: | 1570 nm |
| 1590nm: | 1610nm |
Features
Applications
Performance Specifications
| Parameter | 2 Channels 4 Wavelenghes | ||
| Mux | Demux | ||
| Channel Wavelength/(nm) | 1270~1610 | ||
| Center wavelength Accuracy/(nm) | ±0.5 | ||
| Channel Spacing /(nm) | 20 | ||
| Channel Passband(@-0.5dB bandwidth (nm) | >13 | ||
| Insertion Loss/(dB) | ≤1.6 | ||
| Channel Uniformity/(dB) | ≤0.6 | ||
| Channel Ripple/(dB) | 0.3 | ||
| Isolation(dB) | Adjacent | N/A | >30 |
| Non-adjacent | N/A | >40 | |
| Insertion Loss Temperature Sensitivity(dB/℃) | <0.005 | ||
| Wavelength Temperature Shifting(nm/℃) | <0.002 | ||
| Polarization Dependent Loss(dB) | <0.1 | ||
| Polarization Mode Dispersion(PS) | <0.1 | ||
| Directivity(dB) | >50 | ||
| Return Loss(dB) | >45 | ||
| Maximum Power Handling(mW) | 500 | ||
| Operating Temperature(℃) | -5~+75 | ||
| Storage Temperature (℃) | -40~85 | ||
| Package dimension(mm) | L100 x W80 x H10 | ||
Above specification are for device without connector
Order Information
| Configuration | Channel No. | Channel | Pigtail Type | Fiber length | Dimensio(mm) | Connector |
| M=Mux D=Demux |
04=4 Channel 08=8 Channel 16=16 Channel
N=N Channel …… |
27=1270nm 47=1470nm 49=1490nm …… 61=1610nm SS=special… |
0=250um 1=900um 2=2.0mm |
1=1m 2=1.5m 3=others |
1= L100 x W80 xH10 2=L140xW100xH15 3=19 1U Rack |
0=None 5=others |
